Three - Multi-colour Plastic Injection Moulding Machine

Model No.

SM-326

Machine Name

Automatic three colour marble effect plastic injection moulding machine

Plasticising Capacity

10.5 gm to 25 gm per second

Screw Diameter

37 mm to 100 mm

Screw Speed

Up to 220 RPM

Injection Pressure

1590 kg cm to 2010 kgcm

System Pressure

160 Bar

Shot Weight

154 gm to 2344 gm per second

Clamping Force

100 ton to 1000 ton

No of Heating Zone

11

Mould Height

160 mm to 1200 mm

Ejector Force

4 ton to 21.5 ton

Ejector Stroke

130 mm to 320 mm

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

Pneumatic

Festo, Germany or equivalent

S.S.R.

Omron Japan or equivalent

Hydraulic System

Mercury Indian or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

127KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

8700 x 2800 x 2800 mm( L x W x H,  Approx. )

Machine Weight

3100 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
