Square Bottom Paper Bag Making Machine With Flexo Printing

Model No.

JA-142

Machine Name

Automatic square bottom paper bag making machine for small bag with online flexo printing

Speed

Up to 15000 bags per hour

Bag Width

80 mm to 200 mm

Bottom Size

50 mm to 105 mm

Bag Tube Length

190 mm to 370 mm

Paper Thickness

45 gsm to 140 gsm

Paper Roll Width

280 mm to 630 mm

Max. Roll Diameter

1100 mm

Reel Inner Diameter

76 mm

Printing Colour

4

Printing Width

700 mm

Printing Length

160 mm to 800 mm

Max. Printing Speed

120 meterper minute

Overprint Precision

0.15 mm

Thickness of Plate

1.7 mm

Ancillary Equipment

Air Compressor

PLC Control

Siemens, Japan or equivalent

Servo Motor

Panasonic, Japan or equivalent

HMI

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

14KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

10600 x 1400 x 1850mm ( L x W x H,  Approx. )

Machine Weight

5500 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
