Monolayer Blown Film Plant For Pptq Material

Model No.

SM-431

Machine Name

Automatic monolayer blown film plant for PPTQ material

Capacity

Up to 110kg per hour

Screw Diameter

55 mm

Lay flat Width

150 mm to 350 mm

Micron Thickness

25 micron to 70 micron

Film Layer

Single

Screw L/D

30:1

Material Used

PP, poly propylene, virgin raw material

Optional Item 1

Hopper loader with dryer

Optional Item 2

Safety chuck with air shaft

Optional Item 3

Extra gunmetal make sizer

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

195KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1800 x 1000 x 1500mm( L x W x H,  Approx. )

Machine Weight

13000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
