Ibc Three Layer Automatic Blown Film Plant

Model No.

SM-451

Machine Name

Automatic IBC three layer automatic blown film plant

Capacity

Up to 600kg per hour

Screw Diameter

45 / 65 / 75 / 90mm

Lay flat Width

900 mm to 2500 mm

Micron Thickness

20micron to 200 micron

Film Layer

Three

Screw L/D

30:1

Material Used

LDPE, LLDPE, virgin raw material

Optional Item 1

Empty shaft loading &unloading system

Optional Item 2

Hydraulic unloading

Optional Item 3

Film thickness measuring system

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

195KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1800 x 1000 x 1500mm( L x W x H,  Approx. )

Machine Weight

12000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
