Drinking Mineral Water Plastic Pouch Packing Machine

Model No.

Marvel LA-553

Machine Name

Drinking mineral water bag sachet pouch packing machine

Machine Category

Vertical form, fill and seal pouch packaging machine

Machine Design

Intermittent motion machine

Filler Type

Advance gravity filler

Suitable to Pack

Fruit juice, Synthetic juice, butter milk and other similar free flow liquid products

Filling Range

100 ml to 1000 ml

Speed

Up to 2000 packs / hour

Pouch Width

100 mm to 150 mm

Pouch Height

75 mm to 250 mm

Sealing Type

Impulse sealing

Sealing Temperature

Up to 250 C  ( 482 F )

Sealing Options

Center Seal

Roll Unwinding

Mechanical

Bag Pulling

Mechanical

Vertical Sealing Jaws Movement

Mechanical

Horizontal Sealing Jaws Movement

Mechanical

Packing Material

Any heat sealable polyethylene ( L.D ) material

Film Thickness

Up to 150 Micron

Film Reel Inner Core Diameter

76 mm

Maximum Film Reel Diameter

400 mm

Optional Item

Online batch code printing attachment

Ancillary Equipment

Out-feed sachet conveyor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Counter

Multispan India or equivalent

Fill & Seal Controller

Multispan India or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

220 Volts, 50 Hz, A.C., Single Phase

( can also be designed as per specific requirement )

Power Consumption

2.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1100 x 1800 x 2000( L x W x H in mm, Approx. )

Machine Weight

900 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
