Automatic Pouch Bag Packaging Machine For Rice

Model No.

Elite - Standard LA-451

Machine Name

Automatic pouch bag packing machine for Rice

Machine Category

Vertical form, fill and seal pouch packaging machine

Machine Design

Pneumatic intermittent motion machine

Filler Type

Volumetric adjustable cup filler

Suitable to Pack

Sugar, Salt, Tea and other similar granules products

Filling Range

200 gm to 2000 gm

Speed

Up to 3000 packs / hour

Pouch Width

160 mm to 370 mm

Pouch Height

150 mm to 500 mm

Sealing Type

Hot bar sealing

Sealing Temperature

Up to 250 C  ( 482 F )

Sealing Options

Center Seal

Roll Unwinding

Motorised

Bag Pulling

Servo based

Vertical Sealing Jaws Movement

Pneumatic

Horizontal Sealing Jaws Movement

Pneumatic

Packing Material

Any Heat Sealable Laminated material

Film Thickness

Up to 150 Micron

Film Reel Inner Core Diameter

76 mm

Maximum Film Reel Diameter

400 mm

Optional Item 1

Online batch code printing attachment

Optional Item 2

Side gusseting attachment

Optional Item 3

Hole punch, euro punch sealer attachment

Optional Item 4

Gas flushing attachment

Ancillary Equipment 1

In-feed product conveyor

Ancillary Equipment 2

Out-feed sachet conveyor

Ancillary Equipment 3

Inline check weigher

Ancillary Equipment 4

Inline metal detector

Ancillary Equipment 5

Pouch Inspection table

Ancillary Equipment 6

Air Compressor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Servo motor& controller

Omron, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

220 Volts, 50 Hz, A.C., Single Phase

( can also be designed as per specific requirement )

Power Consumption

2.5 KW per hour(Approx.)

Working Temperature

-10 C to 40C (14F to 104F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1600 x 1500 x 2800( L x W x H in mm, Approx. )

Machine Weight

800 Kg.(Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
