Automatic Tarpaulin Lamination Plant

Model No.

SM-531

Machine Name

Automatic tarpaulin lamination plant

Capacity

Up to 400kg per hour

Line Speed

Up to 120 meter per minute

Screw Diameter

75 / 90 / 100 mm

Die Width

2000 / 2250 / 2650 / 3250 / 4200 mm

Optional Item 1

Pneumatic brake for unwinder

Optional Item 2

Sandwich unwinder

Optional Item 3

Pre-heating system

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

75KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

7000 x 3000 x 3000 mm ( L x W x H,  Approx. )

Machine Weight

65000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
