Automatic Jumbo Bag Size Cutting Machine

Model No.

SM-621

Machine Name

Automatic jumbo bag size cutting machine

Speed

Up to 25meter perminute

Length

4000mm

Width

1200 / 2200 mm

Suitable For

FIBC bag

Optional Item 1

Spout cutting with web guiding system &die

Optional Item 2

Two side folder with ultrasonic welding &pneumatic brake

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

55KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2800 x 1500 x 1300 mm( L x W x H,  Approx. )

Machine Weight

4500 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
