Automatic Double Cavity Pet Stretch Blow Moulding Machine

Model No.

SM-205

Machine Name

Automatic double cavity pet stretch blow moulding machine

Speed

Up to 2500 bottles perhour

Number of Cavity

2

Cavity Pitch

100 mm to 130 mm

Mould Thickness

160 mm to 170 mm

Clamping Stroke

190 mm

Stretching Stroke

350 mm to 450 mm

Bottom Stroke

50 mm to 75 mm

Preform Holders

56 / 128

Maximum Neck Diameter

25 mm to 30 mm

Maximum Product Diameter

75 mm to 110 mm

Product Volume

100 ml to 2000 ml

Product Height

340 mm

Heating Zone

6 / 8

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

45KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2600 x 2650 x 2500mm( L x W x H,  Approx. )

Machine Weight

2500 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
