Web Offset Printing Machine For Pamphlet Paper & Magazine Book

Model No.

PR-321

Machine Name

Web offset printing machine for magazine book

Printing Speed

16000 to 36000 copies per hour

Pages & Colour

32& 4

Plate Width

889 mm

Plate Length

539 mm to 661 mm

Plate Thickness

0.28 mm

Blanket Length (T bar type including bars)

556 mm to 678 mm

Blanket Length (narrow-gap including bars)

580 mm to 702mm

Blanket Width

889 mm

Blanket Thickness (including packing)

1.65 mm + 0.45 mm/ 1.95 mm + 0.2 mm

Paper Width

650 mm to 889 mm

Maximum Reel Diameter

1070 mm

Maximum Printing Length T Bar Type Blanket

482 mm to 604 mm

Maximum Printing Length Narrow-gap Blanket

495 mm to 617 mm

Paper gsm (uncoated)

38 gsm to 80 gsm

Cut Off Length

508 mm to 630 mm

Broad Sheet Size

325 mm to 444 mm

Tabloid Size

254 mm to 315 mm

Quarter fold

162.5 mm to 222 mm

Optional Item 1

Motorized registration system

Optional Item 2

Brush dampening

Optional Item 3

Spray dampening

Ancillary Equipment 1

Air compressor

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

A.C Frequency Drive

Delta - Taiwan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2500 x 1500 x 1500 mm( L x W x H,  Approx. )

Machine Weight

2000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
