Triangle Shape Sachet Packing Machine

Model No.

Wonder LA-232

Machine Name

Automatic triangle sachet packing machine for making triangular pouches

Machine Category

Vertical form, fill and seal pouch packaging machine

Machine Design

Pneumatic intermittent motion machine

Filler Type

Volumetriccup filler

Suitable to Pack

Snacks food, Tea,Coffee, Confectionery and other similar granules products

Filling Range

50 gm to 500 gm

Speed

Up to 2500 packs / hour

Pouch Width

30 mm to 175 mm

Pouch Height

60 mm to 300 mm

Sealing Type

Hot bar Sealing

Sealing Temperature

Up to 250 C  ( 482 F )

Sealing Options

Center Seal with triangular shape

Roll Unwinding

Mechanical

Bag Pulling

Mechanical

Vertical Sealing Jaws Movement

Mechanical

Horizontal Sealing Jaws Movement

Pneumatic

Packing Material

Any heat sealable laminated plastic film or poly coated paper

Film Thickness

Up to 150 Micron

Film Reel Inner Core Diameter

76 mm

Maximum Film Reel Diameter

400 mm

Optional Item 1

Online batch code printing attachment

Option Item 2

Nitrogen flushing attachment

Ancillary Equipment 1

In-feed product conveyor

Ancillary Equipment 2

Out-feed sachet conveyor

Ancillary Equipment 3

Inline check weigher

Ancillary Equipment 4

Inline metal detector

Ancillary Equipment 5

Pouch Inspection table

Ancillary Equipment 6

Air Compressor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Stepper Motor

Sanyo Denki Japan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Digital Control Unit

Multispan India or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

220 Volts, 50 Hz, A.C., Single Phase

( can also be designed as per specific requirement )

Power Consumption

2.5 KW per hour(Approx.)

Working Temperature

-10 C to 40C (14F to 104F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1000 x 860 x 2000( L x W x H in mm, Approx. )

Machine Weight

700 Kg.(Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
