Toilet Soap Group Over Wrapping Machine

Model No.

CS-841

Machine Name

Plastic over wrapping machine for group packing of toilet soap

Speed

Up to 3000 packs per hour

Packet Length

500 mm

Packet Width

250 mm

Packet Height

150 mm

Bundles row & layer

Up to 2 row and layer

Type of Seal

Side seal envelope pack

Packing Material

Any heat sealable both sides heat sealable BOPP and laminated paper etc.

Optional Item 1

Online batch code printing attachment

Optional Item 2

Soap feeding conveyor

Ancillary Equipment 1

Air Compressor

Ancillary Equipment 2

Packing table

Ancillary Equipment 3

Power generator

Main Motor

Siemens - Germany or equivalent

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Servo Motor

Omron, Japan or equivalent

Servo Motion Control

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Digital Temperature Controller

Omron - Japan or equivalent

Main Gear Box

Bonfiglioli- Italy or equivalent

Switch Gears

Schneider - France or equivalent

Power Supply

230 Volts, 50 Hz, A.C., Single phase

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

3793 x 1200 x 1600 mm( L x W x H,  Approx. )

Machine Weight

950 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
