Tea, Coffee Sugar Horizontal Ffs Pouch Packing Machine

Model No.

LB-121

Machine Name

Tea, coffee, sugar horizontal FFS pouch packing machine

Machine Category

Horizontal form, fill and seal pouch packaging machine

Filler Type

Advance volumetric cup filler

Suitable to Pack

Tea, coffee, sugar and other similar granules products

Filling Range

50 gm to 1000 gm

Speed

Up to 3000 packs / hour

Pouch Width

85 mm to 300 mm

Pouch Height

120 mm to 400 mm

Sealing Type

Hot bar sealing

Sealing Temperature

Up to 250 C  ( 482 F )

Sealing Options

Stand-up, Side Gusseted, Four side seal, Zipper doypack

Roll Unwinding

Mechanical

Bag Pulling

Mechanical

Vertical Sealing Jaws Movement

Pneumatic

Horizontal Sealing Jaws Movement

Pneumatic

Packing Material

Any heat sealable laminated material

Film Thickness

Up to 150 Micron

Film Reel Inner Core Diameter

76 mm

Maximum Film Reel Diameter

400 mm

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

Out-feed sachet conveyor

Ancillary Equipment 2

Inline check weigher

Ancillary Equipment 3

Inline metal detector

Ancillary Equipment 4

Pouch Inspection table

Ancillary Equipment 5

Air Compressor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Servo motor

Omron, Japan or equivalent

Servo motion control

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

220 Volts, 50 Hz, A.C., Single Phase

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2900 x 1050 x 1470( L x W x H in mm, Approx. )

Machine Weight

1000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
