Small Biscuits Sachet Pouch Packaging Machine

Model No.

LA-113

Machine Name

Automatic small biscuit sachet pouch packaging machine

Machine Category

Biscuit & Bakery Machines

Filler Type

Volumetric telescopic cup filler

Filling Range

50 gm to 100 gm

Speed

Up to 2000 packs perhour

Pouch Width

45 mm to 150 mm

Pouch Height

60 mm to 200 mm

Sealing Type

Hot bar Sealing

Sealing Temperature

Up to 250 C  (482 F )

Sealing Options

Center seal / Three side seal / Four side seal

Roll Unwinding

Mechanical

Bag Pulling

Mechanical

Vertical Sealing Jaws Movement

Mechanical

Horizontal Sealing Jaws Movement

Mechanical

Packing Material

Any heat sealable laminated plastic film or poly coated paper

Film Thickness

Up to 150 Micron

Film Reel Inner Core Diameter

76 mm

Maximum Film Reel Diameter

300 mm

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

In-feed product conveyor

Ancillary Equipment 2

Out-feed sachet conveyor

Ancillary Equipment 3

Inline check weigher

Ancillary Equipment 4

Inline metal detector

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Digital Control Unit

Multispan India or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

220 Volts, 50 Hz, A.C., Single Phase

( can also be designed as per specific requirement )

Power Consumption

1.2 KW per hour(Approx.)

Working Temperature

-10 C to 40C (14F to 104F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

800 x 670 x 2050 ( L x W x H in mm )

Machine Weight

360 Kg.(Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
