Pickles Preformed Stand-up Bags Pouch Packing Machine

Model No.

LB-256

Machine Name

Pickles preformed readymade stand-up bags pouch packing machine

Machine Category

Horizontal pick, fill and seal pouch packing machine

Filler Type

Advance pneumatic filler

Suitable to Pack

Mango pickles, Lemon pickles, and other similarproducts

Filling Range

100 gm to 2000 gm

Speed

Up to 2000 packs / hour

Pouch Width

100 mm to 300 mm

Pouch Height

150 mm to 450 mm

Pouch Type

Centre seal pouch, side seal pouch, gusseted pouch, stand-up pouch

Sealing Temperature

Up to 250 C  ( 482 F )

Packing Material

Any heat sealable laminated plastic film or poly coated paper

Film Thickness

Up to 150 Micron

Optional Item 1

Online batch code printing attachment

Optional Item 2

Gas flushing attachment

Ancillary Equipment 1

Out-feed sachet conveyor

Ancillary Equipment 2

Inline check weigher

Ancillary Equipment 3

Inline metal detector

Ancillary Equipment 4

Pouch Inspection table

Ancillary Equipment 5

Air Compressor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Servo motor

Omron, Japan or equivalent

Servo motion control

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three Phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

4.0 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

1800 x 1600 x 2300( L x W x H in mm, Approx. )

Machine Weight

1300 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
