Paper Carton Packing Machine For Toilet Soap

Model No.

CS-831

Machine Name

Automatic paper carton box packing machine for toilet soap

Speed

Up to 7000 packs per hour

CartonLength

50 mm to 150 mm

CartonWidth

20 mm to 65 mm

CartonHeight

15 mm to 200 mm

Air Required

6 bar pressure 0.5 CFM

Packing Material

Any mono paper carton etc.

Optional Item 1

Online batch code printing attachment

Optional Item 2

Soap feeding conveyor

Ancillary Equipment 1

Air Compressor

Ancillary Equipment 2

Packing table

Ancillary Equipment 3

Power generator

Main Motor

Siemens - Germany or equivalent

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Servo Motor

Omron, Japan or equivalent

Servo Motion Control

Siemens, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

Digital Temperature Controller

Omron - Japan or equivalent

Main Gear Box

Bonfiglioli- Italy or equivalent

Switch Gears

Schneider - France or equivalent

Power Supply

230 Volts, 50 Hz, A.C., Single phase

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

3900 x 1200 x 1800 mm( L x W x H,  Approx. )

Machine Weight

850 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
