High speed linear container filling machine with twin volumetric cup filler ( up to 5 kg)

Machine Name

High speed linear container filling machine with twin volumetric cup filler

Machine Category

Container filling line

Filling Range

Up to 5 kg

Filler Type

Advanced volumetric cup filler

Speed

Up to 70containersperminute

Container Diameter

Up to 200 mm

Container Height

Up to 300 mm

Optional Item

Online batch code printing attachment

Container Type

Any round, square and flat plastic, metal &glass container

Ancillary Equipment 1

In-feed turn table

Ancillary Equipment 2

Out-feed turn table

Ancillary Equipment 3

Bottle inspection table

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Main Motor

Siemens, Japan or equivalent

Pneumatic

Festo Germany or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Variable Frequency Drive

Delta, Taiwan or equivalent

Switch Gears

Schneider, France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three Phase ( can also be designed as per specific requirement )

Power Consumption

7.5 KW per hour (Approx.)

Working Temperature

-10 C to 40 C ( 14F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Weight

1000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
