Container Bottle Filling Line For Tea, Sugar, Salt

Model No.

LC-271

Machine Name

Tea, sugar, salt container bottle filling machine

Machine Category

Container filling line

Machine Design

Linear indexing motion

Filler Type

Volumetric cup filler

Suitable to Pack

Sugar, Salt, Tea and other similar granules products

Filling Range

100gm to 1000 gm

Speed

Up to 2000 bottles / hour

Bottle Type

Any round, square and flat plastic and glass bottle

Bottle Diameter

22 mm to 100 mm

Bottle Height

55 mm to 240 mm

Height of Conveyor

910 mm to 960 mm adjustable

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

In-feed screw conveyor

Ancillary Equipment 2

In-feed turn table

Ancillary Equipment 3

Out-feed turn table

Ancillary Equipment 4

Bottle inspection table

Ancillary Equipment 5

Packing conveyor

Ancillary Equipment 6

Air compressor

Programmable Logic Controller ( PLC )

Omron, Japan or equivalent

HMI Touch Screen

Omron, Japan or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Variable Frequency Drive

Delta, Taiwan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three Phase withNeutral

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour(Approx.)

Compressed Air Requirement

6 bar pressure 0.5 CFM

Working Temperature

-10 C to 40C (14F to 104F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2500 x 1350 x 2200( L x W x H in mm, Approx.)

Machine Weight

1500 Kg.(Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
