Bottle Filling Line Machine For Ginger & Garlic Paste

Model No.

LC-261

Machine Name

Bottle filling line machine for ginger & garlic paste

Machine Category

Container filling line

Machine Design

Linear indexing motion

Filler Type

Volumetric paste filler

Suitable to Pack

Tomato paste, Ginger paste, Garlic paste and other similar paste products

Filling Range

10 ml to 1000 ml

Number of Filling Head

2 / 4 / 6 / 8

Speed

Up to 6000 bottles / hour

Bottle Type

Any round, square and flat plastic and glass bottle

Bottle Diameter

22 mm to 100 mm

Bottle Height

55 mm to 240 mm

Height of Conveyor

910 mm to 960 mm adjustable

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

In-feed turn table

Ancillary Equipment 2

Out-feed turn table

Ancillary Equipment 3

Bottle inspection table

Ancillary Equipment 4

Packing conveyor

Ancillary Equipment 5

Air compressor

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Variable Frequency Drive

Delta, Taiwan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three Phase withNeutral

( can also be designed as per specific requirement )

Power Consumption

3.5 KW per hour (Approx.)

Compressed Air Requirement

6 bar pressure 0.5 CFM

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

2135  x 1050 x 1450  ( L x W x H in mm, Approx.)

Machine Weight

1000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
