Automatic Non-woven Fabric Bag Making Machine

Model No.

SM-751

Machine Name

Automatic non-woven fabric bag making machine

Bag Width

200 mm to 1200 mm

Bag Side Width

Up to 180 mm

Bag Height

200 mm to 680 mm

Non-Woven Fabric Thickness

30 gsm to 120 gsm

Speed

Up to 7000 bags per hour

Suitable Material

PP non-woven fabric material

Sealing mode

Ultrasonic hot sealing

Material of Construction

Mild steel with powder coating

Ancillary Equipment 1

Air compressor

Ancillary Equipment 2

Water chiller

PLC Control

Siemens, Japan or equivalent

HMI

Siemens, Japan or equivalent

Servo Motor

Panasonic, Japan or equivalent

Pneumatic

Festo, Germany or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Photo Mark Sensor

Datalogic U.S or equivalent

Ultrasonic Sealing System

Emerson U.S or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with Neutral

( can also be designed as per specific requirement )

Power Consumption

15 KW per hour (Approx.)

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Machine Dimension

4350 x 1500 x 1600 mm( L x W x H,  Approx. )

Machine Weight

3000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
