Automatic Injectable Vial Packaging Line

Product Name

Automatic injectable vial packaging line

Product Category

Packaging machine

Product Group

Vial packaging line

Filling Range

1 ml to 100 ml

Number of Filing Head

4 / 6 / 8 / 12

Speed

Up to 12000vials / hour

Vial Type

Glass vial

Vial Diameter

14 mm to 55 mm

Vial Height

Up to 120 mm

Stopper Diameter

13 mm to 20 mm

Height of Conveyor

850 mm to 900 mm adjustable

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

In-feed turn table

Ancillary Equipment 2

Out-feed turn table

Ancillary Equipment 3

Packing conveyor

Ancillary Equipment 4

Power generator

Ancillary Equipment 5

Voltage stabilizer

Floor Space Requirement

25 Square Meters

Height requirement

3000 mm

Skilled Men Power Requirement

2

Unskilled Men Power Requirement

2

PLC Control

Siemens, Japan or equivalent

Servo Motor

Panasonic, Japan or equivalent

HMI

Siemens, Japan or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with neutral

( can also be designed as per specific requirement )

Connected Load

About 5 KW

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Total Weight

4000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
