Automatic Disinfectant Bottle Packing Line

MachineName

Automatic disinfectant bottle packing line

MachineCategory

Bottle packaging line

Machine Group

Packaging machine

Filler Type

Volumetric piston filler

Filling Range

100 ml to 1000 ml

Number of Filling Head

2 / 4 / 6 / 8 / 10

Speed

Up to 6000 bottles / hour

Bottle Type

Any round, square and flat plastic bottle

Bottle Diameter

22 mm to 100 mm

Bottle Height

55 mm to 240 mm

Height of Conveyor

910 mm to 960 mm adjustable

Optional Item

Online batch code printing attachment

Ancillary Equipment 1

In-feed turn table

Ancillary Equipment 2

Out-feed turn table

Ancillary Equipment 3

Bottle inspection table

Ancillary Equipment 4

Power generator

Ancillary Equipment 5

Voltage stabilizer

Floor Space Requirement

30 Square Meters

Height requirement

4000 mm

Skilled Men Power Requirement

2

Unskilled Men Power Requirement

3

PLC Control

Siemens, Japan or equivalent

Servo Motor

Panasonic, Japan or equivalent

HMI

Siemens, Japan or equivalent

AC Variable Drive

Delta, Taiwan or equivalent

Pneumatic

Festo, Germany or equivalent

Main Motor

Siemens, Japan or equivalent

Main Gear Box

Bonfiglioli Italy or equivalent

Digital Temperature Controller

Omron, Japan or equivalent

Switch Gears

Schneider France or equivalent

Power Supply

440 Volts, 50 Hz, A.C., Three phase with neutral

( can also be designed as per specific requirement )

Connected Load

About 10 KW

Working Temperature

-10 C to 40 C (14 F to 104 F )

Working Humidity

Up to 90 percentage

Noise Level

Up to 80 dbA

IP Protection Class

IP54

Working Hours

24 hours per day

Total Weight

5000 Kg. (Approx.)

Note

Exact specifications may vary and shall be made available upon specific request.
